| Product Name | P/N: | Availability | Price | Qty |
|---|---|---|---|---|
| 1U Wallmount Rack | 1URACK-110 |
In stock
|
$159.99
|
|
| 2U Wallmount Rack | 2URACK-110 |
In stock
|
$189.99
|
You may also be interested in the following product(s)
| Product Name | P/N: | Availability | Price | Qty |
|---|---|---|---|---|
| Pair of Brackets for 1U Wall Mount | 1URACK-110-REAR-BRKTS |
In stock.
|
$15.99
|
|
| Pair of Brackets for 2U Wall Mount | 2URACK-110-REAR-BRKTS |
In stock.
|
$15.99
|
Features
The wall mount rack provides 1U or 2U of usable rack space anywhere it's needed. The wall mount rack can be used to mount equipment horizontally or vertically. It allows 1U or 2U tall 19" rack mount equipment to be mounted to a wall, under a desk or stacked on a desk or table.The wallmount rack is compatible with most OEM slide rails: Dell, HP, IBM, Apple, Sun, Intel, Cisco, Juniper, and 3Com. This rack is compatible with round hole, threaded hole and square hole equipment and slides. The wall mount server rack supports equipment up to 30" deep, including slide rails and cable management. The cover protects the unit while allowing for proper ventilation. Airflow and cooling are handled with front and rear openings, airspace above and below the server and louvers on each side. Wall mount hardware is included.
Wall Mount Rack - Technical Specifications
| Rack Units | 1U or 2U |
| Dimensions | 1U: 2.3" (58 mm) height x 28.5" (725 mm) deep x 20" (508 mm) wide 2U: 4.1" (104 mm) height x 28.5" (725 mm) deep x 20" (508 mm) wide |
| Wallmount Equipment Width | EIA Standard 19" equipment |
| Wallmount Equipment Depth | Max: 30" (762 mm) |
| Weight Capacity | 1U: 50 lbs (23 kgs) 2U: 100 lbs (45 kgs) |
| Wall Anchors | Eight anchors included in kit Total shear strength 540 lbs (vertical) Total pullout strength 160 lbs (horizontal) |
| Finish | Black, textured, powder coat |
| Included Hardware | All required hardware is included |
| Assembly Notes | Phillips head screwdriver required |
| Tech Notes | 1) Wall mounting in any orientation (hardware and screws provided) 2) Under desk mounting (may require additional hardware depending on the desk design) 3) Stack-able on desktops |
