Dell PowerEdge 750, SC1425, 1850 Rails

P/N: 1URAIL-750

Dell 750, SC1425, 1850 compatible

  • Alternative to OEM slide rails
  • Fixed (non-sliding) rails
  • No cable management arm
  • Does not require the Dell RapidRail or VersaRail kit
  • Supports L, C, Z and ? rack upright shapes

Fits in any 2 or 4Post Rack

  • Works with square, round and threaded holes
  • 4Post, 2Post center or flush mount
  • Center or flush mounts in Telco, relay racks

Be the first to review this product

Items in stock ship from our warehouse tomorrow!
Product Name P/N: Availability Price Qty
Dell PowerEdge 750, SC1425, 1850 Rails 1URAIL-750
In Stock
$89.99

Features

The 1URAIL-750 replaces the Dell rail kit. This rail kit allows the Dell PowerEdge 750 to be installed into any 4Post or 2Post racks. Common installation issues such as obstructions are easily resolved with the 1URAIL-750. In circumstances where the original Dell rails have been lost or damaged, the 1URAIL-750 provides an economical solution for replacing the OEM rail kit.

Dell PowerEdge 750, SC1425, 1850 Rails - Technical Specifications

Rail OEM Dell
Server Compatibility Dell PowerEdge 750
Dell PowerEdge SC1425
Dell PowerEdge 1850
Rack Type 4Post
2Post - center mount
2Post - flush mount
Rack Type 4Post, 2Post
Rail Type Fixed (non-sliding)
Rack Units 1U
Mounting Depth Range 4Post: 11' - 31" (279 - 787 mm)
2Post center or flush: 2" - 8" (51 - 203 mm)
Included Hardware 10-32 and 12-24 screws supplied
Cage nuts provided for square hole racks
Finish Zinc plated
Tech Notes Dell rails not required
Threaded, front flange mates with the Dell thumb screws (10-32 threads)
Assembly Notes Requires a Phillips screwdriver for installation
