Front view - DL585 mounted with HP's rails in 4Post rack

 Front view - DL585 mounted with HP's rails in 4Post rack

Hover to View, Click to Zoom

  • Front view - DL585, 4Post mounted with 3UKIT-109 Universal Rails
  • Side view - DL585, 4Post mounted with 3UKIT-109 Universal Rails
  • Rear view - DL585, 4Post mounted with 3UKIT-109 Universal Rails

HP DL585 G7 - Rackmount Rail Guide

P/N: HP-DL585-G7

HP Standard 3U-7U Universal Rail Kit

Used for most square hole racks, round hole racks or threaded hole racks. Rack mounting depth must be between 24" and 36"

2Post center mount

  1. Convert 4U of 2Post rack to 4Post using HP's rails and a
    2POST-4UKIT. One kit mounts one server.
    Compatible with upright depths from 3 - 6" (76 - 152 mm)
  2. If you don't have HP's universal rail kit, use RackSolutions'
    Universal Rails, 3UKIT-009

2Post flush mount

  1. Convert 4U of 2Post rack to 4Post using HP's rails and a 4UKIT-003
    One kit mounts one server.
    Compatible with upright depths from 3 - 6" (76 - 152 mm)
  2. If you don't have HP's universal rail kit, use RackSolutions'
    Universal Rails, 3UKIT-009

4Post square hole racks

  1. Use HP's standard 3U - 7U universal rail kit or
    RackSolutions' Universal Rails, 3UKIT-109
  2. Call RackSolutions for depths less than 23 3/4"

4Post round hole racks

  1. Use HP's standard 3U - 7U universal rail kit or
    RackSolutions' Universal Rails, 3UKIT-109
  2. Call RackSolutions for depths less than 23 3/4"

4Post threaded hole racks

  1. Use HP's standard 3U - 7U universal rail kit or
    RackSolutions' Universal Rails, 3UKIT-109
  2. Call RackSolutions for depths less than 23 3/4"

Double 2Post racks

  1. Use HP's standard 3U - 7U universal rail kit or
    RackSolutions' Universal Rails, 3UKIT-109
  2. Call RackSolutions for depths less than 23 3/4"

Rack Issues, Problems

  1. Call RackSolutions if you have racking issues or if your rack is not in the ranges listed above.
Note: Your server may look different than the one pictured

Be the first to review this product

Items in stock ship out today if you complete your order in the next 9 hours and 6 minutes!
Product Name P/N: Availability Price Qty
4U, 2Post Conversion Kit 2POST-4UKIT
In Stock
$189.99
3U, 2Post Rack Rails 3UKIT-009
In Stock
$189.99
4U Flush Mount Conversion Kit for 2Post Racks 4UKIT-003
In Stock
$199.99
3U, Universal Rack Rails 3UKIT-109
In Stock
$159.99
