Adjustable Switch Shelf

$69.99
In stock
SKU
108-6899

Most versatile switch shelf on the market

  • Fits switch widths from 6.3" to 11.4"
  • Equipped with a plated side tray to store power brick and cords
  • Includes a hook-and-loop strap to secure power bricks and cables to the shelf
  • Unused switch space is filled in the front to prevent improper airflow
  • Constructed of 16 GA steel
  • Comes fully assembled for a quick and easy install

RackSolutions has custom-designed the most adjustable switch shelf on the market. With the ability to slide down to 6.3" and slide back out to 11.4", this shelf has the capability to adjust to your equipment dimensional needs. Because this shelf is interchangeable with a variety of switches and routers, we constructed it from 16 GA steel to withstand the wear and tear of reusing our shelf over and over. This shelf is equipped with a tray built-in for your power bricks and cords to rest on. Also included is a hook-and-loop strip to prevent your cords from sticking out or hanging below your shelf. Rubber bumpers are incorporated to place on the rear end of the shelf to prevent your switch from falling out, and a sliding lock is built in to ensure your adjusted shelf width is locked in place to hold your product. The adjustable switch shelf comes fully assembled and is ready to install into your 2 post or 4 post rack. The front of the shelf is designed like a blanking panel to fill the empty space after determining your sliding width. Compatible switch brands include Cisco Meraki, Cisco, Ubiquiti, Netgear, Dell, and HPE. See the compatibility attachment above or check the tech specs for a list of all products.

Adjustable Switch Shelf to match data equipment widthAdjustable Switch Shelf to match data equipment width

Adjusts to needed equipment width

The shelf can slide down to 6.3" and out to 11.4" to adapt to your switch size and fills in the unused space with the appearance of a blanking panel.

Power Brick and Cord StoragePower Brick and Cord Storage

Power Brick and Cord Storage

The plated side tray serves as a storage area for your power brick and cords. Use the included hook and loop strip to secure your cords from hanging below or interfering with other U spaces.

More Information
Shelf Type Vented
Rack Type 2 Post
Fixed/Sliding Fixed
Finish Black powdered coat
Mounting Depth Range Mounting Depth: 7.9"
Mounting Width Range: 6.3" - 11.4"
Included Hardware (4) 10-32 Phillips Head Screws
(4) 12-24 Phillips Head Screws
(4) 12-24 Square Nuts
(4) 12-24 Cage Nuts
Weight Capacity 10 lbs
Rack Units 1U
Tool-less/Standard Standard
Hole Type 12-24 Thread
Note: can be installed into a square hole rack with the included cage nuts
Material 16 GA Steel
TAA Compliant Yes
RoHS Compliant Yes
Tech Notes Compatibility:

Cisco Meraki
MS120-8-HW
MS120-8LP-HW
MX64
MX64W
MX65
MX65W
MX67
MX67W
MX67C
MX68
MX68W
MX68CW

Cisco
SF100D-05
SF100D-08
SF100D-08P
SG100D-05
SG100D-08
SG100D-08P
SF110D-05
SF110D-08
SF110D-08HP
SF110D-16
SG110D-05
SG110D-08
SG110D-08HP
SG200-08
SG200-08P
SG200-10FP
SF300-08
SF302-08
SF302-08P
SF302-08PP
SF302-08MP
SF302-08MPP
SG300-10SFP
SG300-10SFP
SG300-10P
SG300-10PP
SG300-10MP
SG300-10MPP

Ubiquiti
Cloud Key Gen 2
UniFi Switch 8
UniFi Switch 8-60W

Netgear
GC110
GC110P
GS908E
GS105Ev2
GS105PE
GS108E
GS108PE
GS305E
GS308E

Eero
Eero Pro
Eero Beacon

Asus
XG-U2008

HPE
HPE OfficeConnect 1405 Switch Series

Dell
Dell EMC Ruckus Wireless Controllers

Vanco
Digital HDMI®/DVI Video Selector A/B Switch
HDMI® 3×1 4K2K Switch
HDMI® 4×1 Selector Switch
HDMI® 4×1 True 4K Selector Switch with ARC and HDR
HDMI® 5×1 4K2K Switch
RGB Component/Composite Audio/Video Selector Switch
HDMI® 1×4 4K Splitter with HDR
HDMI® 1×2 4K Splitter with HDR
