Open Frame 2Post Desktop Server Racks
8U-12U of Rackable Space
- Depth: 12.6” (322 mm)
- Universal square mounting holes
- Mounts shallow EIA 19" equipment
- Included hardware: Screws (20) and Cage nuts (20) 12-24 Threads
Small Footprint, Low Cost
- Rubber feet keep the rack in place
- Cable tie-downs points along the uprights
- Lightweight,14-gauge steel construction
- Quick and easy assembly
Our Desktop Open Frame 2 Post rack is an efficient way to rack mount shallow equipment while taking up little space. Available in 8U and 12U, mount shallow EIA 19" equipment, such as switches, patch panels, small office equipment, and audio/visual equipment. The desktop server rack open frame allows beneficial ventilation and easy access to mounted hardware for maintenance. The two uprights on the desktop rack include universal square holes for universal mountings. The desktop open frame rack is constructed of 14 gauge steel with a weight capacity of 150lbs. Our free standing desk top rack is made in the USA and has rubber feet under each upright to restrict movement of your network rack. Included assembly hardware is 20 screws and 20 cage nuts, 12-24 threads and is flat-packed with the rack, saving in shipping costs.
Improve Efficiency and Accessibility
The rack features an open frame, free standing design that saves space with a small footprint. It gives you the ability to place rack-mount equipment on any surface in your office, such as your desk and makes it easy to access your equipment on a daily basis.
Low-Cost Mounting Solution
With this 2-post rack, you can mount equipment at a fraction of the cost of conventional racks. The lightweight rack is constructed of solid 14 gauge steel, ensuring a sturdy and safe mounting solution.
| Made In America | Yes | BABA Compliant | Yes | RoHS Compliant | Yes | TAA Compliant | Yes | UL Compliant | No | ETL Compliant | No | Country of Manufacture | United States | Rack Type | 2 Post Rack (Telco Rack) | U Height | 4U - 9U, 10U - 19U | Rack Type | 2 Post | Rack Depth Range | 10" - 19" | Rack Overall Width | 19.75" | Rack Hole Type | Square Hole | Weight Capacity | 125 - 250 lbs | Synnex Part Number | 111-5383 - 5023270 111-6428 - 5751290 | Finish | Black textured powder coat |
|---|
Kit Contents:
- (2) Vertical Posts (Left & Right)
- (2) Depth Braces (Left & Right)
- (1) Width Bracket
Mounting Hardware:
- (4) .250 x .500 Pan Head Screw
- (2) .250 x .500 Flat Head Screw
- (4) Lock Washers
Kit Contents:
- (2) Vertical Posts (Left & Right)
- (2) Depth Braces (Left & Right)
- (1) Width Bracket
Mounting Hardware:
- (4) .250 x .500 Pan Head Screw
- (2) .250 x .500 Flat Head Screw
- (4) Lock Washers
