OCP Open Rack 22OU - 48OU

Availability: In stock

OCP Open Rack 22OU - 48OU
  • 48OU Open Compute Project Open Frame Rack with Rails - Top View
    48OU Open Compute Project Open Frame Rack with Rails - Top View
    close
  • 48OU OCP Open Frame Rack with Rails - Side View
    48OU OCP Open Frame Rack with Rails - Side View
    close
  • 48OU Open Compute Project Open Frame Rack - Front View
    48OU Open Compute Project Open Frame Rack - Front View
    close
  • 48OU Open Compute Project Open Frame Rack with Rails - Side View
    48OU Open Compute Project Open Frame Rack with Rails - Side View
    close
  • 22OU Open Compute Project Open Frame Rack
    22OU Open Compute Project Open Frame Rack
    close
Made in America

22OU-48OU of Rackable Space

  • 42" of physical depth will easily fit in existing data centers
  • Compatible with OCP 21" Equipment
  • Static load 3000 lbs
  • Robust steel frame

Rack Units: 22OU, 42OU, 48OU

  • Rack top with cable pass through
  • Bus bars NOT included
  • Configurable for up to 3 bus bars

Ships fully assembled. Loading dock or lift gate required for delivery.

See "Additional Information" for Tech Specs.

Rack Solutions Promise
Standard Freight Shipping to continental US (1 per rack)   +$199.99 151DC-FREIGHT-OF

* Required Fields

From: $199.99

To: $1,194.99

Price as configured: $0.00

Price as configured: $0.00

Description

Details

Designed to meet the Open Rack V1.1 standard for the Open Commute Project. RackSolutions Open Rack V2 OCP Rack features up to 48OU of rackable space for power shelves, servers and switches. The open commute rack is designed to support up to 3 powerzones with 1 to 3 bus bars. These OCP Open Commute racks ship fully assembled on a pallet.

We promise you’re going to have a great experience. We’ll help you figure out what you need, get it to you fast, and we’ll stand behind it.

What is the Open Compute Project? (OCP) The Open Compute Project started in 2011 and stems from Facebook’s initiative to improve energy efficiency, reduce hardware costs, and speed up deployment, by developing their own custom servers, power supplies, server racks and battery backup systems. The rack and equipment itself has evolved from a standardized 19” EIA rack with specialized IT servers to a unique rack with wide equipment and centralized power. For more info on OCP click here.
Additional Information

Additional Information

Hole Type OCP v1.1 with half OUs
Tech Notes
  • Static load capacity - 3000 lbs
  • Integrated vertical cable management bars
Finish Durable, powder coat finish
Assembly Notes Ships fully assembled on a pallet
Rack Outside Dimensions Height:
  • 22OU: 49.5" (1257 mm)
  • 42OU: 87.25" (2216 mm)
  • 48OU: 98.5" (2502 mm)
  • Width: 23.6" (600 mm)
    Depth: 42" (1067 mm)
    Rack Casters Heavy Duty 3" Casters
    Rack Units 22OU, 42OU, 48OU
    RoHS Compliant Yes
