Vertical Rackmount Powerstrips
CSA certified and UL recognized
- 15A Plug type: NEMA 5-15P | Receptacle: NEMA 5-15R
- 20A Plug type: NEMA L5-20P | Receptacle: NEMA 5-20R
Learn more about receptacle & plug types (opens in a new tab).NOTE: Each power strip requires a mounting bracket when mounted on Rack Solutions Rack 111 open frame rack
Installs at the rear of most 19" EIA server racks
- 15A and 20A models available
- 8, 16, and 24 outlet models available
- Twist lock plugs available on 20A models
- Not surge protected
The Vertical Rackmount Powerstrips are installed at the rear of the server racks. These power strips are available with 8, 16, or 24 outlets. The power strip has a color-coded ON/OFF switch to indicate power. These models are available with either a 15A or a 20A circuit breaker to prevent overcurrent situations. The Rack Mount Power Strip is CSA Certified and UL Recognized.
Power Strip Mounting Bracket
The Vertical rackmount power strips on this page require these mounting brackets for mount on our Rack 111 cable management bar.
24 Outlet Power Strip
The 24 Outlet power strips are made for our 44U tall racks with the option of 15amp or 20amp.
16 Outlet Power Strip
8 Outlet Power Strip
| Cord Length | 15 foot |
|---|---|
| Surge Protection | Yes |
| Powerstrip Certification | CSA certified, UL recognized under the component program of UL Standards C22.2 (No. 21-95, 42-99) Standards UL (UL1363) |
| Surge Suppression | No |
| Receptacles & Plugs | NEMA 5-15P, NEMA 5-15R, NEMA L5-20P, NEMA 5-20R |
| Number of Outlets | 8 Outlets, 16 Outlets, 24 Outlets |
| Powerstrip Orientation | Vertical |
| Amperage | 15A, 20A |
| Tech Notes | Vertical rackmount powerstrips mount in the rear space of a server cabinet The internal frames of server cabinets vary Different installation methods must be utilized in some circumstances |
| Synnex Part Number | PSV-F8-15A-Q - 4771867 PSV-F16-15A-R - 5527735 PSV-F16-20A-U - 4942640 PSV-F24-15A-S - 5527736 PSV-F24-20A-V - 4742438 RACK-111-PSMOUNT - 4771866 PSV-F8-20A-T - 5527737 |
| Ingram Part Number | PSV-F8-15A-Q - PG5628 PSV-F16-15A-R - E66437 PSV-F16-20A-U - T32998 PSV-F24-15A-S - NA1114 PSV-F24-20A-V - PF1238 RACK-111-PSMOUNT - NA1115 |
| RoHS Compliant | Yes |
| Assembly Notes | Fully Assembled |
| TAA Compliant | No |
