Modular Shelf Bracket for Lenovo P3 Ultra
Lenovo P3 Ultra PC Brackets Designed for the Modular ShelfÂ
- Simply drop the workstation into placeÂ
- I/O ports are accessibleÂ
- Fit multiple on the 4 post shelf and Cantilever shelf
Modular Shelf Bracket Compatibility
- Mounts 4 Lenovo P3 Ultra workstations (101-9076)
The Lenovo P3 Ultra Modular Shelf Bracket allows you to securely store and manage your devices into place. You can group the devices by size or operating system, which will help those who are testing for small-scale deployments. We provide PC brackets specifically designed for the Lenovo P3 Ultra (101-9076). You can fit multiple devices on the Modular 4 post shelf or 2 post shelf.
These brackets feature built-in obrounds that fit flush with the legs of your workstation, ensuring that your device is placed in the correct position. The faceplate of the bracket allows airflow from the front of the rack to directly exhaust to the rear, so you can be confident that your devices will not overheat.
No Interference With The Cold Air Intake
For optimal cooling and thermal efficiency, the PC bracket does not interfere with the cold air intake and exhaust ports.This allows the intake and exhaust of the rack shelf to separate the hot and cold air. The airflow from the front of the PC bracket cutout directly exhausts to the rear, so you can be confident that your devices will not overheat.
PC Mounting Stabilization
To keep the devices in place, the PC brackets feature obround cutouts to act as a stabilizer. This prevents your devices from wobbling or shifting on the rack shelf. For Lenovo P3 Ultra workstations, you can easily be fasten your devices into the obround cutouts of the Lenovo bracket.
Cabling Organization and Accessibility
The open design of the PC bracket does not interfere with the power button or peripheral ports. This allows for your PC cables to seamlessly route through the back of the bracket. Additionally, the design leaves vacant space for PC cables while still providing access to the I/O ports.
| Made In America | Yes | BABA Compliant | Yes | RoHS Compliant | Yes | TAA Compliant | Yes | UL Compliant | No | ETL Compliant | No | Country of Manufacture | United States | OEM Compatibility | Lenovo | Generation | Gen1, Gen2 | Product Line | ThinkStation | Form Factor | Small, Tiny | Device Type | Computer | Finish | Black, Textured Powder Coat | Material | Steel |
|---|
Kit Contents:
- (1) Base Plate
- (1) Face Plate
Bracket Hardware:
- (5) #8-32 x .250" Flat Head Screw
Mounting Hardware:
- (3) #8-32 Keps Nut
Kit Contents:
- (1) Modular Shelf
- (2) Ball Bearing Slides (Left & Right)
- (2) Rear Rail Brackets (Left & Right)
- (1) Cable Management Attachment
Assembly Hardware:
- (8) 8-32 x .375 Truss Head Screws
- (8) 8-32 Keps Nuts
- (2) 8-32 x .312 Flat Head Screws
Mounting Hardware:
- (9) 10-32 x .500 Pan Head Screw
- (9) 12-24 x .500 Pan Head Screw
- (9) 12-24 x Square Nut
- (9) 12-24 x Cage Nut
Assembly Components:
- (1) Left Rail
- (1) Right Rail
- (2) Retainer Brackets
Cable Arm Hardware:
- (1) Cable Arm Assembly
- (2) CMA Extension Brackets (L/R)
- (1) Hook and Loop
Components:
- (1) Shelf
Mounting Hardware:
- (4) 10-32 Pan Head Screws
- (4) 12-24 Pan Head Screws
- (4) 12-24 Cage Nuts
- (4) 12-24 Square Nuts
2U Cable Management Arm Hardware:
- (6) 12" Zip Ties
- (1) 50" Hook and Loop
- (1) Plastic Lanyard 6"
- (1) Chassis Bracket with Adhesive
Rack Mount Hardware:
- (3) 12-24 Square Nuts
- (3) 10-32 Pan Head Screws, 3/4"
- (3) 12-24 Pan Head Screws, 3/4"
- (3) 12-24 Cage Nuts "Black"
- ThinkStation P3 Ultra Gen2 Workstation
- ThinkStation P3 Ultra Workstation
- ThinkStation P360 Ultra Workstation
