115-B Tilting Wall Mount for Dell SFF
Wall mount a Dell OptiPlex 780 SFF
- Only Compatible with SFF PCs - Full Compatibility Below
- 75 mm and 100 mm VESA hole pattern
- Wallmount bracket supports up to 50 lbs
- Includes all required mounting hardware
- PC & Monitor not included
Customize to your needs
- Compatible with most flat panel displays
- Pairs great with one of our keyboard wall mounts
- Tilt and fixed monitor options available
NOTE: PC & Monitor NOT included.
Dell Compatible Products
Optiplex 780 Small Form Factor (SFF)
Optiplex 960 Small Form Factor (SFF)
Optiplex 980 Small Form Factor (SFF)
RackSolutions' Dell OptiPlex 780 SFF Wall Mount creates a wall mounted compact all-in-one solution for Dell OptiPlex 780 Small Form Factor (SFF) PCs. Using 75 mm and 100 mm VESA mounting patterns, the wall mount allows almost any flat panel display to be paired with the PC and wall mount. There are two options when choosing a Dell OptiPlex 780 USFF Wall Mount, a version that stays fixed, and an upgraded version that allows your monitor to tilt to be positioned to your needs. For a fully wall mounted system, try combining the setup with one of our keyboard wall mounts. All required mounting hardware is included
| VESA Standard | Hole Pattern | Monitor Weight | Screen Size |
| FDMI MIS-C | 75 x 35 mm | ≤ 10 lbs / ≤ 4.5 kg | 8" to 11.9" |
| FDMI MIS-D | 75 x 75 or 100 x 100 mm | ≤ 30.8 lbs / ≤ 14 kg | 12" to 23.9" |
| FDMI MIS-E | 200 x 100 mm | ≤ 50 lbs / ≤ 23.7 kg | 24" to 30.9" |
For more information on VESA Mounting Standards and what VESA stands for visit VESA Mounting Standards Explained. (opens in a new tab)
| Made In America | Yes | BABA Compliant | No | RoHS Compliant | Yes | TAA Compliant | Yes | UL Compliant | No | ETL Compliant | No | Weight (lbs) | 9.200000 | Country of Manufacture | United States | OEM Compatibility | Dell | Product Line | OptiPlex | Form Factor | Small | Weight Capacity | 30 - 100 lbs | Finish | Black, textured powder finish | Dell Part Number | 104-2095: A5602172 For a full list of Dell SKUs setup in the Dell ordering system visit our Dell SKU page | Ingram Part Number | 104-2095 - GE7778 |
|---|
Assembly Components:
- (1) Main Bracket
- (1) Pivot Assembly
Monitor Hardware Package:
- (8) Nylon Spacers
- (5) M4 x 10mm Pan Head Screws
- (5) M4 x 18mm Pan Head Screws
- (5) M4 x 25mm Pan Head Screws
Wall Mount Hardware Package:
- (4) Pan Head Screws
- (4) Anchors
Pivot Hardware:
- (5) 8-32 Flat Head Screws
- Optiplex 780 SFF
- Optiplex 960 SFF
- Optiplex 980 SFF
