12U TechEdge Wall Mount Rack 18in Depth
Easily wall mount networking equipment
- Mounting hardware included: (20) 12-24 screws, (20) cage nuts, (8) drywall anchors
- Constructed of high quality 14 and 16 gauge steel
- Corner brace attachments enhance stability
- Black powder coat finish
Front mount up to 12U of rack equipment
- Stud center mounting holes 16" apart
- Self-squaring for easier installation
- Mounting depth 18.05"
- 200lb capacity
- Square holed
RackSolutions TechEdge product line offers high-quality manufacturing in the USA at a low cost. Whatever your industry, we've got a TechEdge product with the quality you need, at an affordable price.
The 12U TechEdge WallMount Rack is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices, and other areas with limited floor space where you need equipment to be secure and out of the way. The TechEdge 12U Wall Mount Rack is self-squaring for easier installation. Constructed from heavy-duty 14 and 16 gauge steel with a durable black powder-coated finish, the rack has a maximum load capacity of 200 pounds with a mounting depth of 18.05". Wall mounting stud holes are 16" apart located on the back of the rack. Lined with squared holes, the 12U TechEdge WallMount Rack is ready for cage nuts to be installed.
All mounting hardware is included: (20) 12-24 screws, (20) cage nuts, (8) drywall anchors.
Stud Center Mounting 16" Apart
The TechEdge 12U Wall Mount Rack is self squaring to ensure every bracket meets 90 degrees to create the perfect square frame.
|Rack Type||Wall Mount|
|Rack Internal Width||EIA 19" Standard Rack|
|Rack Mount Depth||18.05in|
|Synnex Part Number||119-6040 - 6069018|
|Included Hardware||20 - 12-24 screws 8 - Drywall Anchors|
|Rack Height ( U Height)||12U|
|Finish||Black powder coat|
|Rack Outside Dimensions||L: 19.72in x W: 18.05in x H: 24.69in|
|Dimensions||Inside L: 19.72in x W: 17.75in x H: 21.13in|
