Data Center Rack Cabinet Enclosures
This Product Ships Freight
Features & benefits
- 48" or 42" of physical depth will easily accommodate modern equipment
- Rack Units: 42U or 48U
- Reversible doors
- Static load of 3000 lbs
- Compatible with overhead cabling and raised floor cabling systems
- Robust steel frame
Unique Features:
- Side panels secured via inaccessible fasteners
- All doors open 180°
- No internal airflow recirculation
- Casters and levelers not required, saving significant cost
- Clearly marked rack units on EIA uprights of the rack
Custom Configurable Racks
The RackSolutions 151DC Data Center enclosed server racks are compatible with Dell, HP and IBM servers and computers. They are also compatible with most other standard brands as well. These server racks meet the EIA standards for 19" server racks.The fully enclosed server racks range in size from a 42U server rack or a 48U server rack, perfect for most any server room or data center. These racks also ship fully assembled and ship on a pallet . Security has been addressed as well, with our locking front and back doors and locking side panels.
Cable Management Bars
Each of these racks come standard with 2 vertical cable management bars. The 5" width of the cable management bars create enough room to mount 2 APC style PDUs side by side. The design allows for the cable management bars to be recessed for maximum airflow pass through.
Casters & Leveling Feet Kit
This user installed upgrade kit adds casters and leveling feet to the rack to allow the rack to move while fully populated with 3000 lbs.Once the rack is rolled into place it can then be set on the leveling feet.
Lock Upgrade (106-4075)
The lock upgrade gives you the option of using the key or combination lock to access the rack. This feature is user install-able even after the purchase of rack. This upgrade changes the locks on the front and rear doors.
30" Wide Cabinet
The 30" Wide Cabinet is ideal as a network rack enclosure. This rack has cable pass throughs on the front uprights that run from the front to the rear of the rack. The extra width allows for high density cabling situations with network switches.
![Cable Tray for 30" Wide Rack (desktop image)](https://www.racksolutions.com/media/product-pages/151-enclosed-cabinet-rack/151DC/137-3111-1.jpg "Cable Tray for 30" Wide Rack (desktop image)")
Cable Tray for 30" Wide Rack
This cable management tray (137-3111) runs horizontally through the depth of the rack (151DC-3969 Only).
Please call for shipping rates to Hawaii, Alaska and Puerto Rico.
Available Heights
18U, 22U, 27U, 32U, 37U, 42U
Available Depths
39" (1000mm)
Available Widths
23.6" (600mm)
Weight Capacity (Static)
1680 lbs
Rack and Stackable
—
19" EIA Square Mounting Holes
✔
Adjustable Mounting Depth
✔
Fully Enclosed Rack with Perforated Locking Doors
✔
(2) Vertical Cable Management Bars Included
—
Customizable Configuration
—
Caster Kit
✔
Available Heights
24U, 32U, 37U, 42U, 48U
Available Depths
42", 48" (1070 mm, 1200mm)
Available Widths
23.6", 31.5" (600mm, 800mm)
Weight Capacity (Static)
3000 lbs
Rack and Stackable
✔
19" EIA Square Mounting Holes
✔
Adjustable Mounting Depth
✔
Fully Enclosed Rack with Perforated Locking Doors
✔
(2) Vertical Cable Management Bars Included
✔
Customizable Configuration
—
Caster Kit
✔
Available Heights
42U, 48U
Available Depths
42", 48" (1070 mm, 1200mm)
Available Width
24", 30" (610 mm, 762 mm)
Weight Capacity (Dynamic)
3000 lbs
Rack and Stackable
✔
19" EIA Square Mounting Holes
✔
Adjustable Mounting Depth
✔
Fully Enclosed Rack with Perforated Locking Doors
✔
(4) Vertical Cable Management Bars Included
✔
Customizable Configuration
✔
Caster Kit
✔
Rack-151
151SW
151DC
Available Heights
18U, 22U, 27U, 32U, 37U, 42U
24U, 32U, 37U, 42U, 48U
16U, 42U, 45U, 48U
Available Depths
39" (1000mm)
42", 48" (1070 mm, 1200mm)
42", 48" (1070 mm, 1200mm)
Available Widths
23.6" (600mm)
23.6", 31.5" (600mm, 800mm)
24", 30" (610mm, 762mm)
Weight Capacity (Static)
1680 lbs
3000 lbs
3000 lbs
Rack and Stackable
—
✔
✔
19" EIA Square Mounting Holes
✔
✔
✔
Adjustable Mounting Depth
✔
✔
✔
Fully Enclosed Rack with Perforated Locking Doors
✔
✔
✔
(2) Vertical Cable Managment Bars Included
—
✔
✔
Customizable Configuration
—
—
✔
| Made In America | Yes | BABA Compliant | Yes | RoHS Compliant | Yes | TAA Compliant | Yes | UL Compliant | No | ETL Compliant | Yes | Country of Manufacture | United States | Rack Type | 4 Post Rack, Enclosed | U Height | More than 40U | Rack Type | 4 Post | Rack Depth Range | More than 40" | Rack Overall Width | 24", 30" | Rack Hole Type | Square Hole | Weight Capacity | 2000 - 4000 lbs | Dell Part Number | 151DC-4071 - A8058820 151DC-4488 - AB009687 For a full list of Dell SKUs setup in the Dell ordering system visit our Dell SKU page. |
Ingram Part Number | 131-4072 - 2LR172 137-3111 - 2LR173 106-4075 - 5KR128 101-2511 - QM1285 151DC-4071 - YB3769 151DC-4070 - YB3770 151DC-3969 - YB3771 | Finish | Durable, powder coat finish |
|---|
Kit Contents:
- (1) 48U 151DC Data Center Rack 24in x 48in
Kit Contents:
- (1) 42U 151DC Data Center Rack 24in x 42in
Kit Contents:
- (1) 48U 151DC Data Center Rack 30in x 42in
Kit Contents:
- (2) Combination or Key Handle Upgrade
Kit Contents:
- (4) Baying Bracket
