Dell R210, R220 Fixed Rails - Shallow Mounting Depth

109-1953

Availability: In stock

Dell R210, R220 Fixed Rails - Shallow Mounting Depth
  • 2Post Flush mounted - Dell R210 Fixed Rails
    2Post Flush mounted - Dell R210 Fixed Rails
    close
  • 2Post Flush mounted with server - Dell R210 Fixed Rails
    2Post Flush mounted with server - Dell R210 Fixed Rails
    close
  • Rear view of 2Post flush mount - Dell R210 Fixed Rails
    Rear view of 2Post flush mount - Dell R210 Fixed Rails
    close
  • Rear view of 2Post Flush mount with server - Dell R210 Fixed Rails
    Rear view of 2Post Flush mount with server - Dell R210 Fixed Rails
    close
Made in America

Fits 2 Post racks and shallow, 4 Post racks

  • Square, round, threaded holes
  • Shallow mounting depth of 15 - 23.5" (381 - 596 mm)
  • Supports L, C, Z, and ? rack upright shapes

Alternative to Dell rail kit

  • Dell rail kit not required

4Post or 2Post, flush mount

  • Purchase P/N: 109-1953

Alternate rails

Rack Solutions Promise
Product Name SKU Price Qty
Dell R210, R220 Fixed Rails - Shallow Mounting Depth 109-1953
$99.99
Description

Details

Features

The Dell R210 & R220 rail kit is a replacement for the Dell rail kit that is provided with the R210 & R220 server. The R210 & R220 rail kit is compatible with 2Post server racks and shallow, 4Post racks. The Dell R210 & R220 rail kit is a fixed rack mounting device. It may be center-mounted or flush-mounted in a 2Post rack. Center mounting in a 2Post rack requires an additional part that comes with P/N: 1UBRK-R4

Additional Information

Additional Information

Compatibility Dell PowerEdge R210
Dell PowerEdge R220
Rail OEM Dell
Fixed/Sliding Fixed
Tool-less/Standard Standard
Included Hardware
    Mounting Hardware:
  • (2) hook plates (left & right)
  • (2) angle bracket
  • (4) 8-32 pan head screws
  • (4) 8-32 flat head screws
  • (4) 8-32 Keps nuts

  • Rack Mount Hardware:
  • (4) 10-32 pan head screws
  • (4) 12-24 pan head screws
  • (4) 12-24 square nuts
  • (4) 12-24 cage nuts
Assembly Notes Phillips screwdriver required
3/8" wrench may be needed to adjust mounting depth
Mounting Depth Range 15 - 23.5" (381 - 596 mm)
Tech Notes The front mounting flange of the rail kit engages the Dell slam latch
2Post and 4Post (shallow) , 19" EIA-310 standard server racks
Finish Zinc plated
Rack Units 1U
Rack Type 2 Post , 4 Post
RoHS Compliant Yes
Hole Type Compatible with the industry standard 3/8" (10 mm) square hole racks
Cage nuts included for square hole mounting
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and metric M6
