100-A Wall Mounts for Dell OptiPlex Micro PCs
Wall mount your Dell OptiPlex Micro PC
- 104-5005 - Fixed
- 104-4935 - Tilted
- Creates a compact all-in-one solution and can mount under a desk
- Uses 75 mm and 100 mm VESA hole pattern
- All required mounting hardware is included
Customizable to your needs
- Tilt bracket option available to adjust monitor
- Works with most flat panel displays
- Pairs great with our keyboard wall mount
- Barrel lock is included with the lock upgrade (101-8412)
NOTE: See "Additional Information" below for compatibility. PC & Monitor NOT included.
Â
The Dell OptiPlex Micro Wall Mount from RackSolutions takes the OptiPlex Micro's already ultra compact design and creates an all-in-one solution, leaving an even smaller footprint making it suitable for almost any work environment. The Dell OptiPlex Micro Wall Mount allows a monitor to be attached using 75 mm and 100 mm VESA hole patterns, making it compatible with most flat panel displays. There are two options when choosing a Dell OptiPlex Micro Wall Mount, a version that allows your monitor to tilt and one that stays fixed. The wall mount can also be mounted under a desk, keeping it hidden and out of the way. For added security, a lock upgrade using a bracket and barrel lock(included with the lock upgrade) is also available. The Dell OptiPlex Micro Wall Mount includes all required mounting hardware so all you need is a Phillips head screwdriver.
For more information on VESA Mounting Standards and what VESA stands for visit VESA Mounting Standards Explained (opens in a new tab).
Compatible Dell Products:
- Dell OptiPlex 7040 Micro
- Dell OptiPlex 7050 Micro
- Dell OptiPlex 7060 Micro
- Dell OptiPlex 7070 Micro
- Dell OptiPlex 7090 Micro
- Dell OptiPlex 9020 Micro
- Dell OptiPlex 3020 Micro
- Dell OptiPlex 3040 Micro
- Dell OptiPlex 3046 Micro
- Dell OptiPlex 3050 Micro
- Dell OptiPlex 3060 Micro
- Dell OptiPlex 3070 Micro
- Dell OptiPlex 3080 Micro
- Dell OptiPlex 3090 Micro
- Dell OptiPlex 5000 Micro
- Dell OptiPlex 5050 Micro
- Dell OptiPlex 5060 Micro
- Dell OptiPlex 5070 Micro
- Dell OptiPlex 5090 Micro
- Dell OptiPlex 7010 Micro
104-4935 - Tilted Bracket
104-5005 - Fixed Bracket
| VESA Standard | Hole Pattern | Monitor Weight | Screen Size |
| FDMI MIS-C | 75 x 35 mm | ≤ 10 lbs / ≤ 4.5 kg | 8" to 11.9" |
| FDMI MIS-D | 75 x 75 or 100 x 100 mm | ≤ 30.8 lbs / ≤ 14 kg | 12" to 23.9" |
| FDMI MIS-E | 200 x 100 mm | ≤ 50 lbs / ≤ 23.7 kg | 24" to 30.9" |
For more information on VESA Mounting Standards and what VESA stands for visit VESA Mounting Standards Explained. (opens in a new tab)
| Country of Manufacture | United States |
|---|---|
| Compatible Products | |
| Dell PC Compatibility | OptiPlex 3020 MFF, OptiPlex 3040 MFF, OptiPlex 3046 MFF, OptiPlex 3050 MFF, OptiPlex 3060 MFF, OptiPlex 3070 MFF, OptiPlex 3080 MFF, OptiPlex 3090 MFF, OptiPlex 5050 MFF, OptiPlex 5060 MFF, OptiPlex 5070 MFF, OptiPlex 5090 MFF, Optiplex 7010 MFF, OptiPlex 7040 MFF, OptiPlex 7050 MFF, OptiPlex 7060 MFF, Optiplex 7070 MFF, OptiPlex 7090 MFF, OptiPlex 9020 MFF |
| Dell Part Number | 104-5005 - A8930316 104-4935 - A8930317 For a full list of Dell SKUs setup in the Dell ordering system visit our Dell SKU page. |
| Synnex Part Number | 104-5005 - 4614617 104-4935 - 4614618 |
| Ingram Part Number | 101-7732 - 9CA727 104-5005 - 7BB558 104-4935 - 9CA726 |
| Compatibility | Dell |
| Assembly Notes | Requires Phillips screwdriver |
| Dimensions | Fixed Monitor Outside Dimensions P/N: 104-5005 H x W x D = 7.06" (179 mm) x 7.69" (195 mm) x 1.91" (48 mm) Tilt Monitor Outside Dimensions P/N: 104-4935 H x W x D = 7.06" (179 mm) x 9.32" (237 mm) x 1.91" (48 mm) |
| Finish | Black, textured powder finish |
| Amazon ASIN | 104-5005 = B01BU64CME 104-4935 = B01DCLXSJS |
| RoHS Compliant | Yes |
| TAA Compliant | Yes |
| Included Hardware |
|
