1U Sliding Keyboard Shelf
Keyboard Shelf Tray For Server Consoles
- PS/2 and USB rack mount keyboard included
- USB conversion cable included
- 54.5" keyboard cable length
- Features cable management arm and hook-and-loop cable ties
- Provides space for mouse, pens, supplies
- Compatible with Dell, HP, and IBM systems
Fits Any 4 Post Rack
- Fits square, round, and threaded holes
- Installation depth from 19” - 30.2" (482 - 767 mm)
- 1U rackmount keyboard
NOTE: Belkin or Raritan KVM Switches are not compatible with these products.
The 1U rack mount keyboard shelf tray installs into any standard 19" 4-post server rack while occupying minimal space. It supports installation depths ranging from 19" - 30.2" (482 - 767.08 mm). The keyboard tray features 88/89 keys and a 54.5" long plug, with the functionality of a 104/105 rack mount keyboard device. With the purchase of the PS/2 keyboard, the RackSolutions USB-to-PS/2 dongle is included.
Additionally, for 2-post rack mounting applications, the 2 Post Center Mount requires the 2POST-2UKIT, while the Flush Mount configuration requires the 4UKIT-003.
Integrated Trackpad
The integrated trackpad eliminates the need for an external mouse, helping reduce clutter and saving space. Built directly into the keyboard tray, it provides convenient and efficient navigation for everyday tasks.
Integrated Cable Management Arm
The integrated cable management arm keeps cords organized and properly routed to reduce tangling and clutter within the rack. The hook-and-loop cable ties help maintain a clean and efficient setup while protecting cables as the keyboard tray moves in and out of the rack.
Sliding Rail Mechanism
The ball-bearing slides allow the keyboard keyboard tray to smoothly slide out of the rack for easy access. Its full-extension design provides comfortable use while keeping the keyboard neatly stored when not in use, making it ideal for demanding IT environments.
| Made In America | Yes | BABA Compliant | No | RoHS Compliant | Yes | TAA Compliant | Yes | UL Compliant | No | ETL Compliant | No | Country of Manufacture | United States | U Height | 1U | Rack Type | 4 Post | Rack Hole Type | 10-32 Thread, 12-24 Thread, M6 Thread | Fixed/Sliding | Sliding | Weight Capacity | 30 - 100 lbs | Dell Part Number | 1UKYB-126: A0431056 1UKYB-126-USB: A5653383 For a full list of Dell SKUs setup in the Dell ordering system visit our Dell SKU page. |
Synnex Part Number | 1UKYB-126-USB - 5386862 | Ingram Part Number | 1UKYB-126-USB - GV9062 |
|---|
Details:
- Kit Contents
- (1) Partially Assembled Shelf
- (1) Mini Black Keyboard (USB)
- (2) Rear Brackets
- (1) Cable Management Bracket
- (2) Cable Management Arms
- (1) USB to PS/2 Adapter
Assembly Hardware Kit:
- (6) 8-32 x 3/8" Phil Flat Screws
- (6) 8-32 Nuts
- (1) 30” Hook and Loop
- (1) 11/16” Cotterless Hitch Pin with Pull Ring
- (3) 1/4” x 1 3/8" Clevis Pin
- (3) .059” x 1 1/8" Cotter Pin
Rack Mount Hardware Kit:
- (8) 12-24 x 1/2” Pan Head Screws Zinc
- (8) 10-32 x 1/2” Pan Head Screws
- (8) 12-24 Cage Nuts
- (8) 12-24 Square Nuts
Details:
- Kit Contents
- (1) Partially Assembled Shelf
- (1) Mini Black Keyboard (USB)
- (2) Rear Brackets
- (1) Cable Management Bracket
- (2) Cable Management Arms
Assembly Hardware Kit:
- (6) 8-32 x 3/8" Phil Flat Screws
- (6) 8-32 Nuts
- (1) 30” Hook and Loop
- (1) 11/16” Cotterless Hitch Pin with Pull Ring
- (3) 1/4” x 1 3/8" Clevis Pin
- (3) .059” x 1 1/8" Cotter Pin
Rack Mount Hardware Kit:
- (8) 12-24 x 1/2” Pan Head Screws Zinc
- (8) 10-32 x 1/2” Pan Head Screws
- (8) 12-24 Cage Nuts
- (8) 12-24 Square Nuts
